Canon imagePROGRAF IPF720 User Manual

Other useful settings
Cutting Roll Paper After Printing (W indows)
This topic describes how to cut roll paper automatically (using the auto cut function) after printing, as well as
how to print a cut line to cut the paper manually .
Note
• Auto cut function is activated on the printer by factory default and when the printer driver is installed.
Follow the steps below to reactivate the function after it is disabled, or to change the setting for printing a
cut line instead.
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then display the printer driver dialog box. ( → P .343)
3. Click the Page Setup tab to display the Page Setup sheet.
4. Click Roll Paper in the L Paper Source list.
5. Click N Auto Cut to display the Automatic Cutting Settings dialog box.
6. T o enable automatic cutting, click Y es in the A Automatic Cutting list. If you prefer to cut the
paper later yourself, click Print Cut Guideline .
7. Click OK to close the Automatic Cutting Settings dialog box.
8. Conrm the print settings and print as desired.
Note
• For tips on conrming print settings, see “Conrming Print Settings (Windows)”. (→P .337)
Roll paper will be automatically cut after printing.
330 Enhanced Printing Options

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
