Canon imagePROGRAF IPF720 User Manual

Printing banners or at other non-standard sizes
Printing on Non-Standard Paper Sizes (W indows)
This topic describes two ways to print on non-standard paper sizes.
• Printing by using Custom Size (→P .262)
• Printing by using Custom Paper Size (→P .264)
Printing by using Custom Size
This section describes how to print using Custom Size based on the following example.
• Document: Scanned image
• Page size: Square of non-standard dimensions (430 × 430 mm [16.9 × 16.9 in])
• Paper: Sheets
• Paper type: Plain Paper
• Paper size: A square sheet (430 × 430 mm [16.9 × 16.9 in])
1. Load the square paper (430 × 430 mm [16.9 × 16.9 in]) in the printer .
2. Choose Print in the application menu.
3. Select the printer in the dialog box, and then open the printer driver dialog box. ( → P .343)
4. Make sure the Main sheet is displayed.
5. In the A Media T ype list, select the type of paper that is loaded. In this case, click Plain Paper .
6. After conrming that D Easy Settings is selected, click Scanned Image in the E Print T arget
list.
262 Enhanced Printing Options

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
