Canon imagePROGRAF IPF720 User Manual

Hard Disk
Checking the Free Hard Disk Space
Y ou can check the space available on the printer ’ s hard disk as follows.
• Using the Control Panel
• Using RemoteUI
• Using imagePROGRAF Status Monitor (Windows)
• Using imagePROGRAF Printmonitor (Macintosh)
Using the Control Panel
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Information , and then press the ► button.
3. Press ▲ or ▼ to select HDD Information , and then press the ► button.
Note
• Y ou can also check the free hard disk space by pressing the Information button three times.
Using RemoteUI
T o view the box list, select Stored Job in Job Management. On the Stored Job page, the free hard disk
space is shown in the upper-right corner when boxes are listed.
For details, refer to the RemoteUI help.
488 Hard Disk

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
