Canon imagePROGRAF IPF720 User Manual

Handling sheets
Manually Loading Paper to the Position for Printing
Y ou will need to advance the paper manually to the starting position for printing after selecting the type of
paper in the Control Panel menu when rolls or sheets are loaded in the following cases, which require a
dif ferent paper feeding method than usual.
• Rolls
If you select a type of paper for which W idth Detection is Off when Chk Remain.Roll is also Off
• Sheets
If you select a type of paper for which W idth Detection is Off
In these cases, printing starts from the position at which the paper has been loaded, so you must load the
paper as far into the Paper Feed Slot as possible.
Manually advance paper as follows.
1. When W idth Detection OFF . OK to continue? is shown on the Display Screen , press ▲ or ▼
to select Leave OFF and then press the OK button.
If you select W idth Detection ON , change the Media Detailed Settings information for that
paper and use the regular feeding method.
2. Keeping the right edge of the sheet aligned with the extended line of the paper alignment line (a)
on the right side of the printer , load the sheet so that the near edge is aligned with the groove (b)
at the far end of the platen.
3. Check the position of the loaded paper and press the OK button.
4. After a menu for selection of the paper size is shown on the Display Screen , press ▲ or ▼ to
select the paper size, and then press the OK button.
Note
• If a print job received requires paper larger than the selected paper , it may soil the Platen .
136 Handling Paper

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
