Canon imagePROGRAF IPF720 User Manual

Printer Driver
Page Options Dialog Box (W indows)
The Page Options dialog box of fers the following settings.
Note
• T o display the Page Options dialog box, on the Layout sheet, click Page Options . ( → P .362)
Setting Item Description
A Print Date
Select where the date is printed, as desired. T o print the time as well, select
B Print T ime Also .
C Print User Name
Select where the user name is printed, as desired.
D Print Page Number Select where the page number is printed, as desired.
E Format Settings Click to display the Format Settings dialog box, which enables you to
complete format-related settings.
Note
• If you specify the same position for multiple items, the items are printed from left to right in this order:
date, user name, and page number .
• When you print multiple pages per sheet using Page Layout Printing or similar functions, these items
will be printed for each page.
364 Windows Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
