Canon imagePROGRAF IPF720 User Manual

Messages regarding printheads
Printhead error
Cause Corrective Action
An incompatible Printhead has been installed. Install a Printhead specied for use with the printer .
( → P .518)
Open the T op Cover . If the Carriage is over the
Platen , replace the Printhead with a new one.
( → P .518)
There is a problem with the Printhead .
If, after opening the T op Cover , you see that the
Carriage is not over the Platen , follow the steps
below .
1. Close the T op Cover and press the Online button.
2. Replace the Printhead .
( → P .518)
Execute printhead cleaning.
Cause Corrective Action
The Printhead nozzles are clogged. Follow these steps to clean the Printhead .
1. Hold down the Stop button for a second or more
to cancel printing.
2. Printhead cleaning options.
( → P .517)
If this message is still displayed, replace the
Printhead .
( → P .518)
Error Message 589

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
