Canon imagePROGRAF IPF720 User Manual

Device Setup Utility
Device Setup Utility
imagePROGRAF Device Setup Utility
imagePROGRAF Device Setup Utility is a utility to establish communication between the printer and
your computer by completing relevant settings. After the printer is installed, for example, you can use
imagePROGRAF Device Setup Utility to complete the network settings initially .
• Starting imagePROGRAF Device Setup Utility will show a list of printers found on the network. In this
list, select the printer (specically , the printer ’ s MAC address) that you want to set up, and then congure
the basic settings from your computer , such as the printer ’ s IP address and the network frame type.
• Y ou can see which printers are online in the network by checking the printer list. Communication
between your computer and these printers is possible.
Note
• W e recommend that your network or printer administrator complete the setup work using
imagePROGRAF Device Setup Utility .
• For details, refer to the imagePROGRAF Device Setup Utility help.
Installing imagePROGRAF Device Setup Utility
Install imagePROGRAF Device Setup Utility from the User Software CD-ROM provided with the printer
as follows:
Important
• In Windows 2000/Windows XP/Windows Server 2003/Windows V ista, you must log on with
administrative rights equivalent to the “Administrator” account.
1. Insert the User Software CD-ROM in the CD-ROM drive.
2. On the Setup Menu window , click Install Individual Software .
3. Click Install in imagePROGRAF Device Setup Utility .
4. Follow the instructions on the screen to proceed with the installation.
Windows Software 377

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
