The printer stops during a print job
The printer stops during a print job
An error message is shown on the Display Screen
Status Corrective Action
An error message is displayed during printing. Check the error message and take action as
necessary .
( → P .576)
The last portion of roll paper was used during a print
job, and paper could not be advanced because the
trailing edge is taped to the roll.
Remove the used roll and insert a new roll.
( → P .1 13)
( → P .1 14)
( → P .1 14)
( → P .82)
The printer ejects blank, unprinted paper
Status Corrective Action
The leading edge of the roll paper was cut to
straighten it.
This operation is normal.
The printer cuts the leading edge of the roll to
straighten it and ejects the scraps when T rim
Edge First in the printer menu is On or when T rim
Edge First is Automatic and the leading edge is
slanted. The printer is ready to print after this initial
preparation.
When Off is selected under T rim Edge First , the
edge is not cut and scraps are not removed.
The Printhead nozzles are clogged. Print a test pattern to check the nozzles and make
sure the Printhead is in good condition for printing.
( → P .516)
Clean the Printhead if the nozzles are clogged.
( → P .517)
A print job was received from an incompatible printer
driver .
Use the correct imagePROGRAF printer driver for
the printer and try printing again.
The printer has received print data that includes HP
R TL commands when Auto Rotate is On .
Set Auto Rotate to Off before attempting to print
again.
( → P .50)
The printer is damaged. Contact your Canon dealer for assistance.
The printer stops when printing a HP-GL/2 job (the
carriage stops moving)
Cause Corrective Action
The printer is analyzing the print job. Either wait a while for printing to resume, or on
the printer Control Panel , set Input Resolution to
300dpi .
( → P .50)
556 T roubleshooting

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
