Cannot print over a network
Cannot print over a network
Cannot connect the printer to the network
Cause Corrective Action
The Ethernet cable is not connected
correctly to the printer ’ s Ethernet port.
1. Make sure the printer is connected to the network with the correct
Ethernet cable, and then turn the printer on. For instructions on
connecting the cable, refer to the Quick Start Guide .
2. Make sure the Link indicator is lit.
The Link indicator is green if the printer is connected via 100
Base-TX and orange if connected via 10Base-T .
If the Link indicator is not lit, check the following points.
• Make sure the hub is on.
• Make sure the end of the Ethernet cable is connected
correctly .
Insert the Ethernet cable until it clicks and locks in place.
• Make sure there is no problem with the Ethernet cable.
If there is any problem, replace the Ethernet cable.
• Check the communication mode with the hub.
Although the printer normally detects the hub
communication mode and transmission rate automatically
(in auto negotiation mode), sometimes the hub settings
cannot be detected. In this case, congure the connection
method manually , specifying the communication mode in
use.
( → P .414)
Cannot print over a TCP/IP network
Cause Corrective Action
The printer ’ s IP address is not congured correctly . Make sure the printer ’ s IP address is congured
correctly .
( → P .378)
( → P .405)
The printer ’ s TCP/IP network settings are not
congured correctly .
Make sure the printer ’ s TCP/IP network settings are
congured correctly .
( → P .408)
The computer you are trying to print from is not
congured correctly .
Make sure the computer ’ s TCP/IP network settings
are congured correctly .
( → P .417)
( → P .436)
T roubleshooting 565

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
