Canon imagePROGRAF IPF720 User Manual

Conserving roll paper
Conserving Roll Paper by Rotating Originals 90 Degrees
(W indows)
This topic describes how to conserve paper by rotating originals 90 degrees before printing, based on the
following example.
• Document: Any type
• Page size: A4 (210.0×297.0 mm)/Letter (8.3×1 1.7 in)
• Paper: Roll
• Paper type: Plain Paper
• Roll paper width: A3/A4 roll (297.0 mm [1 1.7 in])
This example illustrates how to rotate an A4 (210.0×297.0 mm)/Letter (8.3×1 1.7 in) original in portrait
orientation 90 degrees to t within the width of A3/A4 roll paper (297.0 mm [1 1.7 in]), which enables you to
conserve paper .
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then open the printer driver dialog box. ( → P .343)
3. Make sure the Main sheet is displayed.
4. In the A Media T ype list, select the type of paper that is loaded. In this case, click Plain Paper .
5. Click the Page Setup tab to display the Page Setup sheet.
300 Enhanced Printing Options

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
