Canon imagePROGRAF IPF720 User Manual

Maintenance Cartridge
Replacing the Shaft Cleaner
Replace the Shaft Cleaner when you replace the Maintenance Cartridge . New Shaft Cleaner is included
with replacement Maintenance Cartridge .
After Maintenance Cartridge replacement, a message on the Display Screen prompts you to replace the Shaft
Cleaner . Select Y es and press the OK button. Next, go to step 3.
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Maintenance , and then press the ► button.
3. Press ▲ or ▼ to select Repl. S. Cleaner , and then press the ► button.
4. Press ▲ or ▼ to select Y es , and then press the OK button.
After the Carriage is moved, the Display Screen indicates Open top cover . .
5. Open the T op Cover .
6. Hold the Shaft Cleaner on the right side of the Carriage by the grips (a) and pull it toward you to
remove it.
Important
• Never touch parts other than those mentioned in the instructions. This may stain your hands and
damage the printer .
Maintenance 533

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
