Canon imagePROGRAF IPF720 User Manual

Control Panel
Paper Menu
Setting Item Description, Instructions
Cut Sheet T ype ( *1 ) Choose the type of sheets.
( → P .132)
Roll Media T ype ( *1 ) Choose the type of roll.
( → P .105)
Chk Remain.Roll Choose On to print a barcode at the end of a roll before you remove it. The
printed barcode can be used in managing the amount of roll paper left. Choose
Off if you prefer not to print the barcode.
Roll Length Set Displayed if Chk Remain.Roll is On .
If a barcode is not printed on rolls, specify the roll length. The roll length is
displayed in meters or feet, depending on the setting in Length Unit .
*1: For information on the types of paper the printer supports, refer to the Paper Reference Guide . ( → P .96)
The types of paper indicated in the printer driver and related software (as well as on the Control Panel )
are updated when you install the printer driver from the User Software CD-ROM or if you update paper
information by using the Media Conguration T ool . See Media Conguration T ool Guide (Windows)
or Media Conguration T ool Guide (Macintosh).
Printer Parts 51

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
