Printing CAD Drawings
HP-GL/2 Printing
This printer supports the original Canon GARO printer control language as well as HP-GL/2 and HP
R TL( *1 ) emulation.( *2 ) When printing from applications that support HP-GL/2 output, specify HP-GL/2 in
the application’ s plotter output settings.
Note
• For instructions on conguring these settings, refer to the software documentation.
The printer automatically switches to the corresponding processing depending on whether a GARO,
HP-GL/2, or HP R TL job is received. Congure the optional settings for HP-GL/2 emulation on the printer
control panel. ( → P .50)
This printer can emulate the following printers using HP-GL/2 emulation.
Emulated Printers
Canon W3000 and W3050( *3 )
Hewlett-Packard Designjet 450c, Designjet 750c Plus, and Designjet 750c
*1: HP-GL/2: Hewlett-Packard Graphics Language 2; HP R TL: Hewlett-Packard Raster T ransfer Language
*2: It may not be possible to print jobs with excessively large amounts of data correctly .
*3: Layout templates are not supported.
162 W orking With V arious Print Jobs

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
