Messages regarding HP-GL/2
Messages regarding HP-GL/2
This type of paper is not compatible with HP-GL/2.
Cause Corrective Action
Replace the paper with a type compatible with
HP-GL/2. For details on paper compatible with
HP-GL/2, refer to the Paper Reference Guide .
( → P .96)
The printer has received a HP-GL/2 print job that
cannot be printed on the paper that has been
advanced.
The printer may continue printing, but the printing
quality may be af fected. Check the printing results.
GL2: Wxxxx The memory is full. (xxxx is 0501, 0903, or
0904)
Cause Corrective Action
The printer memory is full. Because the entire print job could not be received,
the printer may not be able to print the entire original.
Check the printing results.
GL2: W0502 The parameter is out of range.
Cause Corrective Action
A parameter specied in a HP-GL/2 command is out
of the supported range.
Check the print job.
GL2: W0504 This command is not supported.
Cause Corrective Action
The printer has received an unsupported HP-GL/2
command.
Check the print job.
Error Message 593

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
