Canon imagePROGRAF IPF720 User Manual

Printing Photos and Images
7. In the A Media T ype list, select the type of paper that is loaded. In this case, click Glossy
Photo Paper .
Make sure the paper you select is loaded in the printer .
Note
• The paper type setting in the printer driver and related software (as well as on the Control Panel ) is
updated when you install the Media Conguration T ool from the User Software CD-ROM or if you
change paper information by using the Media Conguration T ool . See the Media Conguration T ool
Guide (Windows) or Media Conguration T ool Guide (Macintosh).
8. After conrming that D Easy Settings is selected, click Photo in the E Print T arget list.
Note
• For information on settings optimized for printing photos and images, see “Printing Photos and
Images (Windows, Mac OS X)”. (→P .144)
• Y ou can check the settings values selected in the E Print T arget list by clicking F V iew set. .
9. Access the Page Setup pane.
10. Click Roll Paper in the A Media Source list.
W orking With V arious Print Jobs 149

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
