Canon imagePROGRAF IPF720 User Manual

Printing banners or at other non-standard sizes
7. Click the Page Setup tab to display the Page Setup sheet.
8. Click O Size Options to display the Paper Size Options dialog box.
9. Complete the following settings in the Paper Size Options dialog box.
1. Enter a desired paper name in Custom Paper Size Name . “430 mm Square” is used in this example.
2. Select mm or inch in Units .
3. Enter “430” (16.9 in) in both W idth and Height .
Note
• If you select the Fix the Ratio of the W idth to Height check box, after you enter a value in either
W idth or Height , the other value will be automatically applied based on the original aspect ratio.
10. Click Add to register “430 mm Square.”
1 1. Click OK to close the Paper Size Options dialog box.
12. Click Cut Sheet in the L Paper Source list.
13. In the A Page Size list, click the size you added, "430 mm Square."
14. Conrm the print settings and print as desired.
Note
• For tips on conrming print settings, see “Conrming Print Settings (Windows)”. (→P .337)
Enhanced Printing Options 265

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
