Canon imagePROGRAF IPF720 User Manual

Other useful settings
Using Favorites (W indows)
This topic describes how to register favorites and print using favorite settings.
Registering a favorite
Follow the steps below to save the current print settings as a favorite.
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then display the printer driver dialog box. ( → P .343)
3. Complete the print settings.
4. Click the Favorites tab to display the Favorites sheet.
5. Click H Add to display the Add dialog box.
6. Complete the following settings in the Add dialog box.
• Enter a desired name in Name , such as “Photos for Presentations” or “Monthly Report.”
• Choose a tting icon for these print settings in the Icon list.
• In Comment , enter a description of the favorite to be added, as desired.
7. Click OK to close the Add dialog box.
The favorite you have added is now displayed in A Favorites .
Note
• T o save a favorite as a le, click J Export and specify the le to save.
326 Enhanced Printing Options

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
