Canon imagePROGRAF IPF720 User Manual

Control Panel
f. Feeder Selection Button
Switches the paper source. Each time you press this button, the paper source switches between the
roll and the sheet, and the corresponding lamp on the Paper Source Section is lit.
g. Display Screen
Shows the printer menu, as well as the printer status and messages.
h. Color Labels
These labels indicate the Ink T ank colors. The labels correspond to the ink levels on the Display
Screen .
i. ◄ Button
Menu mode: Press this button to display the menu one level higher .
j. ▲ Button
Of ine mode: Press this button to rewind the roll manually . ( → P .1 18)
Menu mode: Press this button to display the previous menu item or setting value.
k. ▼ Button
Of ine mode: Press this button to feed the roll manually in the direction of ejection, as needed.
( → P .1 18)
Menu mode: Press this button to display the next menu item or setting value.
l. ► Button
Menu mode: Press this button to display the menu one level lower .
m. OK Button
In Menu mode, press this button to conrm or execute the selected item or setting. Press this
button if the Display Screen indicates to do so.
n. Information Button
Displays printer submenus. Press this key to display information about ink, paper , and so on.
( → P .65)
Y ou can also hold down this button for three seconds to clean the Printhead ( Head Cleaning A ).
o. Power Button
T urns the printer on and of f. ( → P .22)
p. Load/Eject Button
By pressing this button, you can check instructions on loading and removing paper . Instructions for
loading paper are shown on the Display Screen if pressed when no paper is loaded, and instructions
for removing paper are shown if paper is loaded.
q. Stop Button
Hold down for at least a second to cancel print jobs in progress or end the ink drying period.
Note
• In Sleep mode, you can press any button except the Power button to bring the printer online again.
Printer Parts 21

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
