Canon imagePROGRAF IPF720 User Manual

Printer Driver
Conrming Print Settings (W indows)
There are two ways to conrm the print settings, as follows.
• Checking a preview of the settings (→P .337)
• Checking a print preview (→P .338)
Checking a preview of the settings
A preview of the settings is displayed on the left side of the Main , Page Setup , and Layout sheets. By
checking illustrations and numerical values in the preview , you can conrm current settings for the page
size, orientation, paper source, layout, and so on.
Display Area
Information Displayed
P T op illustrations Illustrations indicate the orientation, page layout, borderless printing
selection, color mode, and other settings information.
Q Middle, bordered area
The page size, paper size, and method and percentage of enlargement
or reduction are indicated.
R Bottom illustrations Illustrations indicate the feed source, orientation, borderless printing
selection, and other settings information.
Note
• T o conrm the Print T arget specied in Easy Settings , click F V iew Settings on the Main sheet to
display the V iew Settings dialog box.
Windows Software 337

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
