Canon imagePROGRAF IPF720 User Manual

Printer Driver
Setting Item Description
K Object Adjustment Select this option to display the Object Adjustment dialog box, in which
you can specify objects subject to color adjustment.
S Defaults
Click to restore all settings on the sheet to the default values.
Note
• For details on settings items, see “Adjusting the Color in the Printer Driver”. (→P .172)
Object Adjustment dialog box
In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If
an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.
Note
• T o display the Object Adjustment dialog box, click Object Adjustment on the Color Adjustment sheet.
Setting Item Description
A Image
Select this option to apply color adjustment to image areas, such as photos.
B Graphics Select this option to apply color adjustment to graphics, such as lines and
circles.
C T ext
Select this option to apply color adjustment to text.
354 Windows Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
