Canon imagePROGRAF IPF720 User Manual

Printer Driver
Setting Item Description
D Fit Paper Size Scales the document image to match the paper size.
E Fit Roll Paper W idth Scales the document image to match the roll width.
F Scaling Resizes the document image based on a specied scaling value.
Enter a value in a range of “5-600.”
G Paper Size
Choose the size of the paper you will print on.
For details on available paper sizes, see “Paper Sizes”. (→P .101)
H Orientation Choose the printing orientation.
Making the Original Orientation Match the Paper Orientation
(→P .319)
K Rotate Page 90 degrees
(Conserve Paper)
Activate this setting to rotate the document image by 90 degrees
before printing.
Conserving Roll Paper by Rotating Originals 90 Degrees (→P .299)
L Paper Source Choose the feed source, as desired.
Options displayed in the list vary depending on the selection in
Media T ype on the Main sheet.
M Roll Paper W idth Choose the roll width.
For details on available roll widths, see “Paper Sizes”. (→P .101)
N Roll Paper Options Complete optional roll paper settings. Click to display the Roll Paper
Options dialog box.
Under A Automatic Cutting , you can specify Y es or No and Print
Cut Guideline .
Cutting Roll Paper After Printing (→P .329)
Select B Banner Printing when printing multiple pages continuously .
Printing Multiple Pages Continuously (→P .274)
P Output Method Click to display the Output Method dialog box, which enables you
to complete the Output Method and Name of data to be saved
settings.
O Size Options
Click to display the Paper Size Options dialog box, which enables
you to register additional paper sizes or select the size system for
use.
S Defaults
Restores all settings on the sheet to the default values.
360 Windows Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
