Canon imagePROGRAF IPF720 User Manual

Printer Driver
Conguration using Advanced Settings
Setting Item Description
A Media T ype
Select the paper type.
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( → P .96)
B Get
Information
Click to display the Get Information dialog box, which shows media types specied
on the printer for each media source. When you select a media source, your
selection is applied to the printer driver settings for the media source and media type.
C Set
Click to display the Media Detailed Settings dialog box for ink drying time and other
detailed settings based on the paper type.
E Print Priority Choose the graphic elements that you want to emphasize for printing.
Giving Priority to Particular Graphic Elements and Colors for Printing (→P .180)
F Print Quality Choose the level of print quality .
Giving Priority to Particular Graphic Elements and Colors for Printing (→P .180)
H Color Mode Choose the color mode.
Giving Priority to Particular Graphic Elements and Colors for Printing (→P .180)
I Set Click to display the Color Settings dialog box for more advanced color settings.
Adjusting the Color in the Printer Driver (→P .172)
J Unidirectional
Printing
Although unidirectional printing is slower , it can help prevent misaligned lines and
ensure better results.
K Reduce Print
Unevenness
This option is displayed if you have selected Plain Paper in A Media T ype and
Ofce Document in E Print Priority .
Activate this option for two-pass printing to reduce color shading.
N Economy Printing When this mode is selected, less ink is consumed than in regular printing, but the
quality is diminished.
Select this mode if you want to conserve ink when checking drawings, for example.
Depending on the Media T ype and Print Quality settings, this mode may not be
available.
L Printer Click to display the Printer dialog box, which indicates the ink levels and gives other
information about the printer .
388 Mac OS X Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
