Canon imagePROGRAF IPF720 User Manual

Network Setting
Conguring the Printer ’ s NetW are Network Settings
Follow the steps below to congure the NetW are network settings.
1. Start the web browser and enter the following URL in the Location (or Address ) box to display
the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon .
3. If a password has been set on the printer , enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the NetW are group to display the Edit NetW are Protocol
Settings page.
6. Refer to the NetW are Settings Items table to complete the settings.
NetW are Settings Items
Item Details
Default Setting
Frame T ype Specify the type of frame to
use in NetW are.
Disabled
NCP Burst Mode Activate this setting to use
NCP Burst Mode.
This mode supports fast data
transfer when printing in queue
server mode. Normally , leave
the setting On.
On
Print Application Choose the print service.
• Bindery PServer
• RPrinter
• NDS PServer
• NPrinter
NDS PServer
Packet Signature Select If Requested by Server
to use packet signature.
If Requested by Server
Bindery
PServer
File Server Name Specify the name of a le
server that has a NetW are print
server .
(0-47 characters)
-
Print Server Name Specify the name of a NetW are
print server .
(0-47 characters)
-
Print Server Password Set a password for the print
server .
(0-20 characters)
-
Polling Interval Specify the interval to conrm
jobs.
(1-15 seconds)
5
RPrinter Print Server Name Specify the name of a NetW are
print server .
(0-47 characters)
-
Network Setting 41 1

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
