Cleaning the Printer
3. Using a damp cloth that you have wrung out completely , wipe inside the T op Cover to clean it.
Wipe away any ink residue on the T op Cover Roller (a), all over the Platen (b), the Paper Retainer
(c), the Borderless Printing Ink Grooves (d), the Ejection Guide (e), and the guide rail (f).
Important
• Do not use a dry cloth to wipe inside the T op Cover . This may create a static charge, which may
attract dust and af fect the printing quality .
• Never use ammable solvents such as alcohol, benzene, or thinner . If these substances come into
contact with electrical components inside the printer , there is a risk of re or electrical shock.
• Never touch the Linear Scale (a) or Carriage Shaft (b).
4. Close the T op Cover .
Maintenance 539

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
