CAPINTEC, INC. CAPTUS
®
600
System Power Requirements
CAUTION
If the input voltage to the following items is not within the stated limits,
the unit may not function correctly or may be damaged.
Line Voltage: 115 or 230 VAC depending on model ordered
Line Frequency: 60 or 50 Hz
Current: 0.7 Ampere @ 115V
0.4 Ampere @ 230V
Fuse: For 115V use T 3.15AH, 250V, (Time Delay)
For 230V use T 2.5AH, 250V, (Time Delay)
Line Filter: Line filter is provided internally.
Use of a filtered line is recommended if excessive line noise is anticipated.
Environment Requirements
Operational
The instrument should be located where the level of the background radiation is as
low and as constant as possible.
The instrument should be located where the temperature is stable within a range of
+50°F to +85°F (+10°C to +30°C) and the maximum relative humidity is 90% non-
condensing to warrant maximum reliability and accuracy.
The instrument should be located where the barometric pressure is within a range of
27–31 inches of mercury (91–105 kilopascals).
Storage
The instrument should be stored where the temperature is stable and the range is
from +39°F to +110°F (+4°C to +43°C) and the maximum relative humidity is 90%
non-condensing to warrant maximum reliability.
The instrument should be stored where the barometric pressure is within a range of
15–33 inches of mercury (51–112 kilopascals).
CAUTION
If these environmental requirements are not followed,
the instrument may display erroneous readings.
November 07 FUNCTIONAL & TECHNICAL DESCRIPTION 2-3
