CAPINTEC, INC. CAPTUS
®
600
To exit from the Patient Selection Screen, press BSP or HOME to return to the main Probe
Screen (
Figure 8-1).
SELECTING PROTOCOL
If more than one protocol has been entered, the Select Protocol Screen (Figure 8-5) will
appear.
14:32
THYROID UPTAKE
> PROT 1
PROT 2
PROT 3
SELECT PROTOCOL
Figure 8-5
Use the ARROW keys to position the cursor next to the protocol to be assigned to this
patient, and press the ENTER key. The Protocol Summary Screen (
Figure 8-6) will appear.
KETCHUM, LIN
PROTOCOL: PROT 1
CALCULATION: ONE CAPSULE
NUCLIDE: I 131
UPTAKES AT: 2 4 24 48 HOURS
COUNTING REPETITIONS: 2
COUNTING PERIOD : 60 SEC
OK? (Y OR N)
Figure 8-6
On this screen, the patient name consists of the entire last name and the first three letters of
the first name.
November 07 THYROID UPTAKE GENERAL INSTRUCTIONS 8-3
