FUNCTION Keys
The Keys labeled F1, F2, F3, F4 – across the top row at the left side of the keyboard – are
function keys. They correspond to the rectangles at the bottom of certain screens (as in
Figure 3-3 and Figure 3-4). The F1 key corresponds to the first rectangle, the F2 key
corresponds to the second rectangle, and so on.
For example, when the screen shows the Probe Screen (
Figure 3-3), pressing the F1 [T/U]
key selects the Thyroid Uptake function; pressing the F4 [BIO] key selects the Staff Bioassay
function. When the screen shows the Well Screen (
Figure 3-4), pressing the F1 [WIPE] key
accesses the Wipe Test Monitor program; pressing F2 [LAB] key accesses programs for
Schilling or Blood Laboratory tests.
When the rectangles at the bottom of the screen are blank, the corresponding function key
does not work for that particular screen.
These keys are sometimes referred to as “SOFT” keys.
PRINT Key
The small square at the lower right side of the function keys corresponds to the PRINT key.
The PRINT key works only when a P appears in this square on the screen. Use the PRINT
key to obtain printouts of measurement results, protocols, patient data, and other reports.
UTIL Key
The UTIL Key accesses the main Utilities menu (Figure 3-5). Utility functions include setting
the time and date on the CAPTUS
®
600 system, calibration, staff data, and system
diagnostics. The UTIL key is active from the Probe or Well Screens.
UTILITIES
1. Multichannel Analyzer
2. Staff Bio Assay Results
3. Setup
4. Diagnostics
0. Return to Probe Screen
14:32
Figure 3-5
