Capintec CAPTUS 600 - Selecting Patient to Measure

CAPINTEC, INC. CAPTUS
®
600
14:32
THYROID UPTAKE
DASILVA, AND
PROTOCOL: 1 CAPSULE
CAPSULE : TU 11:09 250.0
UPTAKE 1: 24%
P
GRAPH
D
EL
E
DIT
M
EAS
μ
UPTAKE 2: TU 15:09
Ci
Figure 8-10
Press F3 [EDIT] to edit patient data.
Press F2 [DEL] to delete patient data
Press F1 [GRAPH] to view the graphic display as shown in
Figure 8-20. Printing can be
done from that display.
Press F4 [MEAS] to make a measurement. The function keys disappear and the prompt
appears at the measurement to be performed.
Press PRINT [P] to print the complete Thyroid Uptake report.
SELECTING PATIENT TO MEASURE
When it is time to perform an uptake, the patient and measurement can be selected from
either the Patient Selection Screen (
Figure 8-2) or the View Screen (Figure 8-10) described
above by pressing F4 [MEAS]. The Measurement Summary Screen (
Figure 8-11) will appear
with the prompt at the measurement to be performed next:
14:32
THYROID UPTAKE
DASILVA, AND
PROTOCOL: 1 CAPSULE
CAPSULE : TU 11:09 250.0
UPTAKE 1: 24%
μ
> UPTAKE 2: TU 15:09
Ci
Figure 8-11
8-6 THYROID UPTAKE GENERAL INSTRUCTIONS November 07
