CAPINTEC, INC. CAPTUS
®
600
checking its system memory. A display similar to Figure 6-19 will appear (the PROM values
shown are just an example). The same results will also be sent to the printer.
14:32
DIAGNOSTICS
RAM: PASS
PROM: PASS
EEPROM: PASS
9B87 7229 1EBE
80EF 3840 2D2C
E710 7892 57F6
Press any key to continue
Figure 6-19
If any of the test results indicate “FAIL” rather than “PASS”, it indicates a system malfunction.
If this happens, perform the Diagnostics Utility again. If the test(s) fail again, contact
Capintec’s Authorized Serve Center for assistance.
CAUTION!
Do NOT continue to use the CAPTUS
®
600
if any Diagnostics test results read “FAIL”.
Diagnostics Printout
On the following pages is a sample Diagnostics printout. Below is a description of the
sections in the Diagnostics
printout.
System Configuration
This data is entered into the system memory at the factory. It indicates to the
CAPTUS
®
600 which detectors are connected on the back panel. The user cannot
change this.
Nuclide Data
Nuclides List
A listing of Nuclides in the CAPTUS
®
600 memory. This list is entered at the factory.
Additional nuclides may be added to this list.
Half-Life
A listing of the Half-life for each nuclide in the CAPTUS
®
600 memory.
Photon Energies
A listing of the Energy Photon Peaks used by the CAPTUS
®
600 in the automatic
peak searching algorithm.
November 07 ACCEPTANCE & QUALITY ASSURANCE TESTS 6-13
