CipherLab 1663 Series - Security Level

To Next Page

To Previous Page

130

Enter Setup

1663 Barcode Scanner User Guide

4.9.4 SECURITY LEVEL

Security Level renders m ore decoding accuracy giving considerat ion to barcodes’ print

quality. Decide t he securit y level for reading EAN- 13 barcodes.

Normal

*High
