6.2.1 SELECT FORMAT TO CONFIGURE
Start Programming Format
Select one edit ing form at (Form at 1~ 5) and t he parameters pertaining to t he edit ing form at can
then be configured – applicable code type, dat a length, m atching string & location, st art position,
field adj ust m ent, tot al num ber of fields, field sett ings (field-dividing rule), addit ional fields, and
field transm ission sequence.
 Up to five different form at s can be specified.
Configure Format 1
Configure Format 2
Configure Format 3
Configure Format 4
Configure Format 5
Not e: Before com pleting t he program m ing of an edit ing form at, if any barcode for
param et ers other t han those pertaining t o the editing form at is read, t he
programm ing process will be autom at ically aborted.
End Programming Format
After having configured all the desired param et ers, you m ust read the “End Program m ing Form at ”
barcode, which can be locat ed at the bott om of every even page in this chapter.
End Programming
Format
