Enter Setup
1663 Barcode Scanner User Guide
EXAMPLE
Without using the scanner to read the above set up barcodes for configuring the 3610
dongle, run HyperTerm inal.exe on the host com puter to send serial com m ands to 3610
via USB Virtual COM.
1) Connect 3610 to t he USB port of PC.
2) The Com m unicat ion LED will indicat e when 3610 can accept serial com m ands after
initializing. Refer to t he t able below.
 I f the out put interface is USB Virtual COM, run HyperTerm inal.ex e on t he host
com puter. While the Comm unicat ion LED on 3610 is purple (red with flashing blue) ,
type the serial com m and wit hin 3 seconds.
 I f the output interface is USB HI D, press the “Num Lock” or “Caps Lock” key via t he
keyboard 5 tim es within 3 seconds while t he Com m unication LED on 3610 is flashing
red and blue. This will change the int erface from USB HI D to USB Virt ual COM and t he
Com m unicat ion LED will becom e purple ( red with flashing blue). Then, run
HyperTerm inal.exe on t he host com puter. While t he Com m unicat ion LED on 3610 is
purple (red wit h flashing blue), t ype the serial com m and wit hin 3 seconds. After
configuring via serial com m ands, t he int erface will reset to USB HI D aft er
re- connecting 3610.
Communication LED
Meaning
--- Blue,
solid
I nitialize
Red,
solid
Blue,
flashing
Serial comm and m ode wit h USB Virtual COM: wait 3 seconds for starting a
serial com m and
Red,
flashing
Blue,
flashing
Serial com m and mode with USB HI D changed to USB Virtual COM first : wait
3 seconds for pressing [ Num Lock] or [ Caps Lock] 5 t imes via keyboard
