CipherLab 1663 Series - Example

217
Update
Appendix III Keyboard Wedge Table
EXAMPLE
KEY TYPE = NORMAL
For exam ple, if you want to program the character “ ! ” as the prefix code:
1) Read t he “Configure Prefix” barcode.
2) Read t he “
Hexadecim al Value” barcode on page 220 for “2” and “1”.
3) Read t he “Validate” barcode to com plet e this setting.
KEY TYPE = SCAN CODE
For exam ple, if you want to program the character “a” ( = “ 1C” on t he scan code table) as t he
prefix code:
1) Read t he “Configure Prefix” barcode.
2) Read t he “Scan Code” barcode.
3) Read t he “
Hexadecim al Value” barcode on page 220 for “1” and “C” .
4) Read t he “Validate” barcode to com plet e this setting.
KEY TYPE = NORMAL + KEY STATUS = SHIFT
For exam ple, if you want t o program the character “! ” (= “Shift” + “1” on keyboard) as t he prefix
code:
1) Read t he “Configure Prefix” barcode.
2) Read t he “Add Shift ” barcode.
3) Read t he “
Hexadecim al Value” barcode on page 220 for “3” and “1”.
4) Read t he “Validate” barcode to com plet e this setting.
KEY TYPE = NORMAL + KEY STATUS = CTRL
For exam ple, if you want to program “Ctrl+ A” and “ Ctrl+ $” as the prefix code:
1) Read t he “Configure Prefix” barcode.
2) Read t he “Add Left Ctrl” barcode.
3) Read t he “
Hexadecim al Value” barcode on page 220 for “4” , “1” (= “A”).
4) Read t he “Add Left Ctrl” barcode.
5) Read t he “
Hexadecim al Value” barcode on page 220 for “2” , “4” (= “$” ) .
6) Read t he “Validate” barcode to com plet e this setting.
