186
End Programming Format
1663 Barcode Scanner User Guide
6.4 CONFIGURE FORMAT — DEFINE DATA FIELD
6.4.1 START POSITION
Data can be divided into fields in one of t he following direct ion –
from head (F1) to tail (F5)
from tail (F1) to head (F5)
*From Head
From Tail
6.4.2 FIELD ADJUSTMENT
You may apply equal length to all fields, if necessary. I f data is found longer than
specified, it will be truncat ed aut om at ically. When data is found shorter, it will add
“ Space” (0x20) t o field.
*No adjustment
Set length to adjust
fields… (*0)
1) Read t he barcode above to adj ust field by length.
2) Read t he “
Decim al Value” barcode on page 219 for the desired field length.
3) Read t he “ Validat e” barcode on t he sam e page t o com plet e t his set t ing.
To Next Page
