4.10 GS1-128 (EAN-128)
*Enable
Disable
Not e: GS1-128 barcodes can be decoded only when this sett ing is enabled. However, for
1660 wit h firm ware version no lat er than 1.30, GS1- 128 barcodes are taken as
Code 128 when this sett ing is disabled.
4.10.1 CODE ID TRANSMISSION
Decide whet her to include the Code I D ("]C1") in the data being t ransm itt ed.
Transmit Code ID
*Do Not Transmit
4.10.2 FIELD SEPARATOR (GS CHARACTER)
Decide whet her to apply a field separator (to convert the FNC1 cont rol character t o hum an
readable charact er).
Enable Field
Separator…
18) Read the barcode above to enable field separator.
19) Read the “
Hexadecim al Value” barcode on page 220 for the desired character string.
20) Read the “ Validate” barcode t o com plet e t his sett ing.
Not e: GS1- 128 barcodes st art with the FNC1 cont rol character to dist inguish them selves
from other uses of Code 128. FNC1 is also used to separate data fields in the
GS1- 128 barcodes.
