196

End Programming Format

1663 Barcode Scanner User Guide

Additional Field 2

Additional Field 3

Additional Field 4

Additional Field 5

Pause Field

Null Character Field

3) Read t he “ End” barcode to com plet e t his set t ing.

End Programming…
