Send documentation comments to mdsfeedback-doc@cisco.com
13-4
Cisco MDS 9000 Family Troubleshooting Guide, Release 3.x
OL-9285-05
Chapter 13 Troubleshooting IVR
Initial Troubleshooting Checklist
Step 1 Choose Fabricxx > All VSANs > IVR to verify your IVR configuration.
Step 2 Select the CFS tab to verify that the Oper column is enabled and the Global column is enabled for CFS
distribution. Check the LastResult column for the status of the last CFS action.
Step 3 Select the Action tab to determine if auto topology and IVR NAT are enabled.
Step 4 Select the Local Topology and Active Topology tabs to verify your IVR VSAN topology.
Step 5 Choose Fabricxx > All VSANs > Domain Manager to verify unique domain IDs if IVR NAT is not
enabled.
Step 6 Choose Zone > IVR > Edit Local Full Zone Database to verify your IVR zones and zone sets and to
verify that you have activated your IVR zone set. The active IVR zone set name appears in bold.
Verifying IVR Configuration Using the CLI
Several commands involving multiple configuration tasks can be used to verify the IVR configuration.
Table 13-1 CLI Commands for Verification of IVR
CLI Command Description
show fcdomain
domain-list
Verifies unique domain ID assignment. If a domain overlap exists,
edit and verify the allowed-domains list or manually configure static,
non-overlapping domains for each participating switch and VSAN.
show interface brief Verifies if the ports are operational, VSAN membership, and other
configuration settings covered previously.
show fcns database Verifies the name server registration for all devices participating in
the IVR.
show zoneset active Displays zones in the active zone set. This should include configured
IVR zones.
show ivr fcdomain Displays the IVR persistent fcdomain database.
show ivr internal Shows the IVR internal troubleshooting information.
show ivr pending-diff Shows the IVR pending configuration.
show ivr service-group Shows the difference between the IVR pending and configured
databases.
show ivr tech-support Shows information that is used by your customer support
representative to troubleshoot IVR issues.
show ivr virtual-domains Shows IVR virtual domains for all local VSANs.
show ivr
virtual-fcdomain-add-st
atus
Shows IVR virtual fcdomain status.
show ivr vsan-topology Verifies the configured IVR topology.
show ivr zoneset Verifies the IVR zone set configuration.
