Send documentation comments to mdsfeedback-doc@cisco.com
20-7
Cisco MDS 9000 Family Troubleshooting Guide, Release 3.x
OL-9285-05
Chapter 20 Troubleshooting IP Storage Services
IP Issues
Verification of Switch Connectivity
Use the procedures in this section to verify connectivity to a destination switch.
Note The FC ID variable used in these procedures is the domain controller address; it is not a duplication of
the domain ID.
Verifying Switch Connectivity Using Fabric Manager
To verify connectivity to a destination switch using Fabric Manager, follow these steps:
Step 1 Choose Fabricxx > VSANxx > Domain Manager to display the domain ID for the destination switch.
Step 2 Concatenate the domain ID with FFFC to obtain the domain controller address. For example, if the
domain ID is 0xda(218), the concatenated ID is 0xfffcda.
Step 3 Choose Tools > Ping... to verify reachability to the destination switch.
Verifying Switch Connectivity Using the CLI
To verify connectivity to a destination switch using the CLI, follow these steps:
Step 1 Use the show fcdomain domain-list vsan command to display the domain ID for the destination switch.
switch# show fcdomain domain-list vsan 200
Number of domains: 7
Domain ID WWN
--------- -----------------------
0x01(1) 20:c8:00:05:30:00:59:df [Principal]
0x02(2) 20:c8:00:0b:5f:d5:9f:c1
0x6f(111) 20:c8:00:05:30:00:60:df
0xda(218) 20:c8:00:05:30:00:87:9f [Local]
0x06(6) 20:c8:00:0b:46:79:f2:41
0x04(4) 20:c8:00:05:30:00:86:5f
0x6a(106) 20:c8:00:05:30:00:f8:e3
Step 2 Concatenate the domain ID with FFFC to obtain the domain controller address. For example, if the
domain ID is 0xda(218), the concatenated ID is 0xfffcda.
