Chapter 13 Troubleshooting IVR
IVR Issues
Link Isolated
Symptom Link isolated.
Persistent FC ID for IVR Failed
Symptom Persistent FC ID for IVR failed.
Table 13-9 Link Isolated
Symptom Possible Cause Solution
Link isolated. Virtual domain overlap. Choose Fabricxx > All VSANs > Domain Manager in
Fabric Manager to verify a domain overlap.
Choose Fabricxx > All VSANs > IVR and select the Action
tab in Fabric Manager.Fill in the Create Virtual Domains for
VSAN field and click Apply Changes. Select the CFS tab
and set ConfigAction to commit, and click Apply Changes.
Or use the show fcdomain domain-list CLI command to
verify a domain overlap. Use the ivr widthdraw domain CLI
command to remove the overlapped domain. Use persistent
FC IDs to reassign the overlapped domain. Use the ivr
virtual-fcdomain-add vsan-ranges CLI command to add
existing and future virtual domains to the domain list for the
selected VSANs.
Repeat this on all edge VSANs.
Internal message payload uses
destination ID.
See the “IVR Network Address Translation Fails” section on
page 13-8.
Table 13-10 Persistent FC ID for IVR Failed
Symptom Possible Cause Solution
Persistent FC ID for
IVR failed.
Selected virtual FC ID does not
match the assigned virtual domain.
Use the show ivr fcdomain database CLI command to verify
the virtual domain ID. Use the
native-autonomous-fabric-num CLI command to assign the
virtual domain and then use the pwwn CLI command to map
the pWWN to an appropriate FC ID that matches the virtual
domain ID.
Refer to the Cisco MDS 9000 Family configuration guides
for the related procedure to configure Persistent FC IDs for
IVR.
