Send documentation comments to mdsfeedback-doc@cisco.com
13-15
Cisco MDS 9000 Family Troubleshooting Guide, Release 3.x
OL-9285-05
Chapter 13 Troubleshooting IVR
Troubleshooting the IVR Wizard
Symptom CFS merge failed.
Troubleshooting the IVR Wizard
The IVR wizard in Fabric Manager simplifies the process of configuring IVR across your fabric. The
IVR wizard automatically checks for the appropriate Cisco SAN-OS version across the switches in the
VSAN and determines which IVR features the switches are capable of. (See Table 13-1.)
This section describes the following warning or error dialog boxes that display when you configure IVR
using the Fabric Manager IVR wizard:
• Warning: Not All Switches Are IVR NAT Capable or Are Unmanageable, page 13-16
• Error: The Following Switches Do Not Have Unique Domain IDs, page 13-16
• Error: Pending Action/ Pending Commits, page 13-17
• Error: Fabric Is Changing. Please Retry the Request Later, page 13-17
Table 13-14 CFS Merge Failed
Symptom Possible Cause Solution
CFS merge failed. IVR topology incorrect. Choose Fabricxx > All VSANs > IVR and select the
Action tab in Fabric Manager. Check the Auto Discover
Topology check box and click Apply Changes. Select the
CFS tab and set ConfigAction to commit and click Apply
Changes.
Or use either the ivr vsan topology auto CLI command to
automatically reconfigure the IVR topology, or the ivr
vsan topology database CLI command to manually
reconfigure the IVR topology.
Maximum number of VSANs or IVR
VSAN topology entries reached.
Reconfigure your fabric before merging to reduce the
number of VSANs or topology entries. See Appendix C,
“Configuration Limits for Cisco MDS SAN-OS Release
3.x.”
Conflicting entries in the AFID
database.
Modify the conflicting entries in the AFID database.
Conflicting user-configured IVR
VSAN topology database entries.
Enable IVR auto topology on both fabrics before the merge
and remove any user-configured IVR VSAN topology
database entries.
