Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV220W Administration Guide 111
6
STEP 4 In the Secure Connection Remote Accessibility section, enter the following
information:
• Remote LAN (Local Network) IP Address (for a Gateway only)—Enter the
subnet IP address of the remote LAN. A subnet IP address is one that gives
the “network number” of the IP range. For example, a network address of
192.168.1.10 with a Subnet Mask of 255.255.255.0 would have a network
number or subnet IP address of 192.168.1.0.
• Remote LAN (Local Network) Subnet Mask (for a Gateway only)—Enter
the associated Subnet Mask for the remote LAN.
• Local LAN (Local Network) IP Address—Enter the subnet IP address of
the local LAN. A subnet IP address is one that gives the “network number” of
the IP range. For example, a network address of 192.168.1.10 with a Subnet
Mask of 255.255.255.0 would have a network number or subnet IP address
of 192.168.1.0.
• Local LAN (Local Network) Subnet Mask—Enter the Subnet Mask for the
local LAN.
Note: The IP address range used on the remote LAN must be different from
the IP address range used on the local LAN.
STEP 5 Click Save to save your settings, or click Cancel to reload the page with the
current settings. After you save your settings, the Advanced VPN Setup
page
appears.
Configuring Advanced VPN Parameters
The Advanced VPN Setup page allows you to configure advanced VPN
parameters, such as IKE and other VPN policies. These policies control how the
Cisco RV220W initiates and receives VPN connections with other endpoints.
• Managing IKE and VPN Policies, page 112
• Configuring IKE Policies, page 113
• Configuring VPN Policies, page 117
• Configuring VPN Users, page 122
