Cisco Small Business RV220W Administration Guide

Installing the Cisco RV220W
Attaching the Antennas
Cisco RV220W Administration Guide 214
A
Attaching the Antennas
The RV220W ships with two removable dual-band antennas.
To attach an external antenna:
STEP 1 Hold the antenna perpendicular to the round screw hole on the back of the unit.
STEP 2 Screw the antenna clockwise until it is firmly secured to the RV220W.
STEP 3 Repeat these steps to secure the second antenna.
STEP 4 Put the antennas in the “V” orientation.
Connecting the Equipment
Before you begin the installation, make sure that you have the following equipment
and services:
Required
• Functional Internet Connection (Broadband DSL or cable modem).
• Ethernet cable for WAN (Internet) connection.
• PC with functional network adapter (Ethernet connection) to run the Device
Manager. The Device Manager is supported on the following web browsers:
- Microsoft Internet Explorer 6.0 or later
- Mozilla Firefox 3.0 or later
- Apple Safari 3.0 or later
• Ethernet cable (provided) to connect the PC to the RV220W for
configuration.
Optional
• Uninterruptible Power Supply (UPS) to provide backup power to essential
devices (strongly recommended).
• Ethernet cables for LAN interfaces, if you want to connect additional
devices.

Cisco Small Business RV220W Specifications

General

Firewall Type	Stateful packet inspection (SPI)
VPN Support	Yes
DHCP Server	Yes
QoS	Yes
Wireless Speed	300 Mbps
Management	Web-based
LAN Ports	4
Encryption	AES
Security Features	NAT, URL filtering
Power Supply	12V DC
Wireless Standard	802.11n
WAN Ports	1
