Configuring Networking
WAN Settings for IPv4
Cisco RV220W Administration Guide 21
2
Adding and Editing PPPoE Profile Settings
Use the Add/Edit PPPoE Profile Configuration page to enter the settings for a
PPPoE profile.
To open this page: From the Networking > WAN (Internet) > PPPoE Profiles
page, click Add or select a profile and then click Edit.
STEP 1 Enter this information:
• Profile Name—Enter a descriptive name to identify the profile (for example,
“ISPOne”).
• Username—Enter the user name for accessing your ISP account (for
example,
john@ISPname.net
).
• Password—Enter the password for accessing your ISP account.
• Authentication Type—Choose one of the following options:
- Auto-negotiate—The server sends a configuration request specifying
the security algorithm set on it. The RV220W then sends back
authentication credentials with the security type sent earlier by the
server.
- PAP—The RV220W uses Password Authentication Protocol (PAP) when
connecting with the ISP.
- CHAP—The RV220W uses Challenge Handshake Authentication
Protocol (CHAP) when connecting with the ISP.
- MS-CHAP—The RV220W uses Microsoft Challenge Handshake
Authentication Protocol when connecting with the ISP.
- MS-CHAPv2—The RV220W uses Microsoft Challenge Handshake
Authentication Protocol Version 2 when connecting with the ISP.
• Connection Type—Choose one of the following options:
- Keep Connected—The Internet connection is always on.
- Idle Time—The Internet connection is on only when traffic is present. If
the connection is idle—that is, no traffic is occurring—the connection is
closed. You might want to choose this if your ISP charges based on the
amount of time that you are connected. If you choose this connection
type, enter the number of minutes after which the connection shuts off in
the Idle Time field.
