Viewing the RV220W Status
Viewing Port Statistics
Cisco RV220W Administration Guide 204
10
• Rx Packets—The number of packets received by the interface.
• Collisions—The number of signal collisions that have occurred on this
interface. A collision occurs when the interface tries to send data at the
same time as a interface on another router or computer that is connected to
this interface.
• Tx B/s—The number of bytes going out of the interface per second.
• Rx B/s—The number of bytes received by the interface per second.
• Uptime—The duration for which the interface has been active. The uptime
will be reset to zero when the RV220W or the interface is restarted.
Poll Interval—Enter a value in seconds for the poll interval. This causes the page
to re-read the statistics from the RV220W and refresh the page automatically. To
modify the poll interval, click the Stop button and then Start to restart automatic
refresh.
Viewing Port Statistics
The Port Statistics page displays port statistics.
To view port statistics:
STEP 1 Choose Status > Port Statistics.
STEP 2 In the Poll Interval field, enter the auto-refresh time interval in seconds.
The default value is 10.
STEP 3 To start the display of port statistics, click Start.
This page displays the latest port statistics based on the value you enter in the
Poll Interval field. For example, if you enter a poll interval value of 5, the router
refreshes the information on this page every 5 seconds.
This table displays the data transfer statistics for the Dedicated WAN, LAN, and
WLAN ports, including the duration for which they were enabled.
