Viewing the RV220W Status
Viewing the VPN Client Connection Status
Cisco RV220W Administration Guide 201
10
• State—The current status of the SA for IKE policies.
Click Connect to establish an inactive SA (connection) or Drop to terminate an
active SA (connection).
The page refreshes automatically to display the most current status. To change the
refresh settings, in the Poll Interval field, enter a value in seconds for the poll
interval. This causes the page to re-read the statistics from the router and refresh
the page automatically. To modify the poll interval, click the Stop button and click
Start to restart automatic refresh.
Viewing the VPN Client Connection Status
Use the Status > VPN Client Connection Status page to view the status of the
VPN client connections.
To open this page: In the navigation tree, choose Status > VPN Client Connection
Status.
The VPN Client Connection Status page displays this information:
Username The username of the VPN user associated with the
QuickVPN or PPTP tunnel.
Remote IP Displays the IP address of the remote QuickVPN
client. This could be a NAT/Public IP if the client is
behind the NAT router.
Status Displays the current status of QuickVPN client.
OFFLINE means that QuickVPN tunnel is not
initiated/established by the VPN user. ONLINE
means that QuickVPN Tunnel, initiated/established
by the VPN user, is active.
Start Time The time of the VPN user establishing a connection.
End Time The time of the VPN user ending a connection.
Duration The duration between the VPN user establishing
and ending a connection.
Protocol The protocol the user uses, QuickVPN or PPTP.
Disconnect Click to disconnect this user.
