Configuring Quality of Service
Profile Binding
Cisco RV220W Administration Guide 151
8
• To bind profiles to traffic selectors, click the Configure Profile Binding
button. See Profile Binding, page 151.
Profile Binding
You can associate your WAN QoS profiles with specified services, network
devices, VLANs, wireless networks, or Differentiated Services Code Point (DSCP)
values. By doing so, you can shape the bandwidth that is available for different use
cases and traffic types. By doing so, you can ensure that the highest possible
bandwidth is available to high priority user groups or services such as SIP for
voice traffic. Likewise, you can limit the bandwidth that is consumed by low
priority user groups such as a wireless guest network or services such as HTTP
for Internet browsing.
• Managing Profile Binding Rules, page 151
• Configuring a Profile Binding Rule, page 152
Managing Profile Binding Rules
Use the QoS > Profile Binding page to view, add, edit, or delete profile binding
rules for your WAN QoS profiles.
To open this page: In the navigation tree, choose QoS > Profile Binding.
Perform the following tasks:
• To add a new profile binding rule, click Add. Then enter the settings on the
Add / Edit Profile Binding Configuration page. For more information, see
Configuring a Profile Binding Rule, page 152.
• To edit a profile binding rule, check the box, and then click Edit. Then enter
the settings on the Add / Edit Profile Binding Configuration page. For more
information, see Configuring a Profile Binding Rule, page 152.
• To delete a profile binding rule, check the box, and then click Delete. When
the confirmation message appears, click OK to continue with the deletion,
or otherwise, click Cancel.
