Configuring Networking
LAN Configuration for IPv4
Cisco RV220W Administration Guide 25
2
STEP 1 Check the VLAN Enable box to enable the creation and management of additional
VLANs. To disable this feature, uncheck the box.
STEP 2 Perform these tasks:
• To add a new VLAN, click Add Row. Then enter these settings:
- VLAN ID—Enter a numerical VLAN ID that will be assigned to endpoints
in the VLAN membership. The VLAN ID can range from 2 to 4094. VLAN
ID 1 is reserved for the default VLAN, which is used for untagged frames
received on the interface, and VLAN ID 4092 is reserved and cannot be
used. After a new VLAN entry is saved, the VLAN ID cannot be changed.
- Description—Enter a short description to identify this VLAN.
- Inter VLAN Routing—Check the box to enable routing between this and
other VLANS, or uncheck the box to disable this feature.
- Device Management—Check the box to enable this feature, or uncheck
the box to disable it. This setting determines whether or not clients can
access the Cisco RV220W Configuration Utility on this VLAN. To prevent
access to this utility from this VLAN, disable this feature.
- Port 1-4—For each of the ports, choose one of the following options:
- Tagged—Used when connecting to switches carrying multiple VLANs.
- Untagged—Access ports connecting to end devices like printers and
workstations.
• To change the settings for an existing VLAN, check the box and then click
Edit. To select all VLANs, check the box in the heading row. Then edit the
settings as described above.
• To delete a VLAN, check the box and then click Delete. To select all VLANs,
check the box in the heading row. When the confirmation message appears,
click OK to continue with the deletion, or otherwise click Cancel.
STEP 3 Click Save to save your settings, or click Cancel to reload the page with the
current settings.
