HelixNet | User Guide
Setting Options
RTS 2-pin
RTS 3-pin
Input Gain -3 dB – 3 dB (default = 0)
Output Gain -3 dB – 3 dB (default = 0)
RMK Input Enabled (default)
Disabled
RMK Output Enabled (default)
Disabled
VOX Enabled (default)
Disabled
VOX Off Delay 0.5 s (default) – 4.0 s
GPO Trigger Enabled (default)
Disabled
Auto-Nulling Start or Stop
4-wire
For each RJ45 port (A & B) configure the following to connect two Channels to an Eclipse Matrix
or any 4-Wire device.
Setting Options
Label Use to give the port a meaningful name
Channel Assignment Choose one from total Channels (12 or 24 depending on license)
Program Output Mute (default)
Unmute
Input Gain -3 dB – 3 dB (default = 0)
Output Gain -3 dB – 3 dB (default = 0)
