Key to HBP-2X Beltpack (Rear view)
Program feed (volume) control wheel. Turn to increase or decrease the overall
listen volume level of the program feed. To assign programs to a Channel, see
Assigning the Program Listen to a Channel and Editing the Program Input.
2.5 mm TRS headset input.
Function
Tip Earphone Positive
Ring Mic Positive
Sleeve Ground
Headset connector (4-pin male or 5-pin female XLR connector).
Pin Function
1 Mic ground
2 Mic positive
3 Earphone ground
4 Earphone positive
Pin Function
1 Mic ground
2 Mic positive
3 Earphone ground
4 Earphone left
5 Earphone right
