Key to example system topologies (layouts) diagram
The second layout uses an XLR Bulkhead and a Mult-box (passive (Y) splitters) to
combine:
A daisy chain (with optional redundancy flyback).
Point-to-point connected beltpacks (using the Mult-box).
The XLR Bulkhead and splitters should be screened.
The complexity and variety of layouts does not restrict physical access to Channels.
Because HelixNet Partyline is a digital system, the HelixNet Stations can access any of
the available Channels (plus a Program Feed), however they are connected to the
Main Station, see diagram in Comparing digital with analog cabling.
